| Model | ZL56-01 | ||||||||
| Working Voltage Range | DC：6-24V | ||||||||
| Rating Power | 1-10W | ||||||||
| Static Water Head | 0.5-4.5M | ||||||||
| Static flow rate | 0.6-4Litre / minute | ||||||||
| Lifespan | Run under normal working conditions＞50000hour | ||||||||
| Working Environment | PH value：PH5-10（Weak acid and weak base）、non-Submersible pump | ||||||||
| Max Noise | Continuous operation under normal working condition (water pump is 1m away from the tester)＜30dB | ||||||||
| Max Working Temperature | At room temperature, the temperature of the aqueous medium≤70℃ | ||||||||
| Application | Computer cooling, small fountain, aquarium, etc. | ||||||||
| Size | IP Grade | Inlet | Outlet | Remarks | |||||
| Length (mm) | Width (mm) | Height (mm) | OD (mm) | ID (mm) | OD (mm) | ID (mm) | Inlet and outlet buckle | ||
| 68 | 68 | 52 | IP65 | φ8 | φ5.5 | φ8 | φ5.5 | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
