| Model | ZLM50-01 | ||||||||
| Working Voltage Range | DC：6-24V | ||||||||
| Rating Power | 6V：10-18W / 12V：10-30W / 24V：20-50W | ||||||||
| Rated speed | 1500-7500Turn / minute | ||||||||
| efficiency | greater than70% | ||||||||
| Use environment | Ambient temperature less than35℃ | ||||||||
| Lifespan | Continuous operation under normal working conditions，life＞10000hour | ||||||||
| Max Noise | Three phase control brushless motor, under normal working condition, andThe pump is 1M away from the tester ＜45Decibel | ||||||||
| Application | Household appliances, medical equipment, automotive oil pumps, etc. | ||||||||
| Size | IP Grade | Exposed shaft parameters | Installation aperture | structure | |||||
| Length (mm) | Width (mm) | Height (mm) | OD (mm) | Shaft extension (mm) | (mm) | ||||
| 71 | 50 | 55 | IP66 | ∮4 | 6 | 4-∮5.5 | Aluminium alloy | ||
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
