Model | ZL38-10 | |||||||
Working Voltage Range | DC: 6V-24V | |||||||
Rating Power | 6V: 0-21W / 12V: 0-21W / 24V: 0-29W | |||||||
Static Water Head | 0-7 M | |||||||
Static Flow Rate | 0-9 L/min | |||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | |||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non submersible) | |||||||
Max Noise | Under normal working status, 1M distance over test instrument <40dB | |||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤70℃ | |||||||
Application | Solar hot water circulation, Medical treatment, Small fountain, Aquarium, etc. | |||||||
Size | IP Grade | Inlet | Outlet | Remark | ||||
Length（mm） | width（mm） | Height（mm） | OD（mm） | ID（mm） | OD（mm） | ID（mm） | Inlet and Outlet with twist lock | |
71.5 | 41 | 93.5 | IP67 | φ20 | φ12.4 | φ20 | φ12.4 | |
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
